GitOps in practice, deploy Kubernetes applications with ArgoCD

GitOps in practice, deploy Kubernetes applications with ArgoCD

Paul-Adrien CORDONNIER

By Paul-Adrien CORDONNIER

Dec 16, 2021

Categories
Containers Orchestration
DevOps & SRE
Adaltas Summit 2021
Tags
Argo CD
CI/CD
Git
GitOps
IaC
Kubernetes
[more][less]

Never miss our publications, subscribe to the Adaltas' newsletter about Open Source, big data and distributed systems. We maintain a low frequency of one email every two months.

GitOps is a set of practices to deploy applications using Git. Application definitions, configurations, and connectivity are to be stored in a version control software such as Git. Git then serves as the single source of truth for the declarative infrastructure and its hosted applications.

Using GitOps means that any change to the deployment must be addressed in a git commit. A continuous delivery operator then diffs the commit and synchronizes the state between the repository and the targeted environment.

The main advantage of GitOps is how every change is versioned and verifiable. Versionning makes it easy to roll back to a previous state in case of errors. Disaster recovery is also simplified. The source of truth remains unchanged and you only need to switch the targeted environment.

The article present how we use ArgoCD to synchronize the state of our Kubernetes clusters. It covers its installation and usages using a simple example application hosted on GitHub.

Since Kubernetes manifests are declarative, it fits perfectly the CI/CD pattern and most GitOps tools focus on Kubernetes.

In practice

It is a good practice to isolate your application source code from your deployment state definitions between 2 distinct Git repositories. YAML files are used to describe the Kubernetes cluster, including Deployments, ConfigMap, Secrets, …

The deployment state repository is organized with the layout:

./myapp-ops
├── base
│   ├── deployment.yaml
│   ├── kustomization.yaml
│   └── service.yaml
├── dev
│   ├── deployment-patch.yaml
│   └── kustomization.yaml
└── prod
    ├── deployment-patch.yaml
    └── kustomization.yaml

Here we are using kustomize for our declarative configuration customization. dev and prod directory defines the state of our application and shares a common base. Dev and Prod can be deployed in the same or different Kubernetes clusters according to our needs.

The typical workflow for a new feature in an application using GitOPs is as follow:

  1. The code is pushed to the code repository.
  2. The code is built and tested in the CI platform.
  3. The code is shipped: a docker image is built and pushed to a registry.
  4. The CI pipeline commits and pushes a new version into to the deployment repository.
  5. This push triggers a synchronization: the new code is automatically deployed to the target infrastructure.

Typical worfklow

Users are free to commit to the deployment repository by themselves, for example they can set the number of ReplicaSet of a deployment.

ArgoCD

ArgoCD is a GitOps operator that synchronizes the state described in a Git repository with a deployment in one or multiple Kubernetes clusters.

ArgoCD supports multiple format for the declarative definitions (Kustomize, Helm, Ksonnet or plain-YAML).

It is implementend as a Kubernetes controller that monitors the Git repository and the live deployment. If for some reason the live status deviates from the target (waiting for user input, deployment failed, manual rollback…), the application is considered OutOfSync.

ArgoCD Installation

A simple ArgoCD installation is straightforward:

kubectl create namespace argocd
kubectl apply -n argocd -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml
# ArgoCD is now installed on your cluster !

# The admin password can be found here:
kubectl -n argocd get secret argocd-initial-admin-secret -o jsonpath="{.data.password}" | base64 -d && echo

# The Web UI and CLI are exposed by the service argocd-server, let's access it:
kubectl patch svc argocd-server -n argocd -p '{"spec": {"type": "LoadBalancer"}}'
# Or if no LoadBalancer provider is available
kubectl port-forward svc/argocd-server -n argocd 8080:443
# Or use an ingress controller

The next step is to install the argocd-cli command following the official ArgoCD CLI installation.

More documentation on the installation (User Management, High Availability, Observability …) are available here.

ArgoCD Usage

Now let’s create an ArgoCD app using the CLI. It can be done easily through the Web UI.

argocd login $myargocd:8443
argocd app create demo-app-dev --repo https://github.com/PACordonnier/demo-cicd-ops.git --path dev --dest-server https://kubernetes.default.svc --dest-namespace dev
# Wait a few minutes
argocd app get demo-app-dev
Name:               demo-app-dev
Project:            default
Server:             https://kubernetes.default.svc
Namespace:          dev
URL:                https://192.168.39.5/applications/demo-app-dev
Repo:               https://github.com/PACordonnier/demo-cicd-ops.git
Target:
Path:               dev
SyncWindow:         Sync Allowed
Sync Policy:        Automated
Sync Status:        Synced to  (babc0df)
Health Status:      Healthy

# Enable autosync
$ argocd app set demo-app --sync-policy auto

# Our application is now Synced and healthy! All changes to our infrastructure repository are automatically applied

Navigating the Web UI, we can see all the objects managed by ArgoCD as well as their current state:

ArgoCD Web UI

Conclusion

If you are using Kubernetes for your deployment and struggle to be aware of what is deployed on your environments, GitOps is for you. Implementing it is no rocket science and can only benefit your DevOps compliance.

ArgoCD is a great product. It solves a real problem while being convenient and easy to use.
